Lincoln Corsair: Body Closures / Removal and Installation - Liftgate Anti-Pinch Switch

Lincoln Corsair 2020-2024 Service Manual / Body and Paint / Body and Paint / Body Closures / Removal and Installation - Liftgate Anti-Pinch Switch

Removal

NOTE: Removal steps in this procedure may contain installation details.

NOTE: LH side shown, RH side similar.

  1. Remove the loadspace trim panel.
    Refer to: Loadspace Trim Panel (501-05 Interior Trim and Ornamentation, Removal and Installation).
  1. Disconnect the liftgate anti-pinch switch electrical connector.
  1. Gently pull to release the pins and remove the liftgate anti-pinch switch.

Installation

  1. To install, reverse the removal procedure.
