Other information:
B Clutch Exploded View
Item
Description
1
Snap ring
2
B (4, 6, R) clutch apply plate
3
B (4, 6, R) clutch piston seals
4
B (4, 6, R) clutch pistons
5
B (4, 6, R) clutch piston return spring
6
B (4, 6, R) clutch fiber plates
7
B (4, 6, R) clutch steel plates
..
Check
NOTE:
Wheel-to-hub optimization is important. Clearance between
the wheel and hub can be used to offset or neutralize the Road Force® or
run-out of the wheel and tire assembly. For every 0.001 inch of
wheel-to-hub clearance, the Road Force® can be affected between 1 and 3
pounds depending on the tire stiffness.
NOTE:
The example below illustrates how the clearance
betw..
